MultiTouch® Displays
MultiTaction® Cell displays are less than 20 cm deep. They accommodate ultra-fast response
time. Sensitivity to external lighting is eliminated.
All MultiTaction Cells:
- Track unlimited touch points, including hands, fingers, fingertips, 2D markers, real-life objects
- Can be set up as a wall or as a table
- Frameless thin bezel design with smooth edge-to-edge front safety glass
- Can easily be embedded in custom furniture
MT550 MultiTaction Cell 55" Full HD LCD
- Modular, stackable to any size and shape
- 55" display unit: physical dimensions 1242 x 713 x 199 mm / 48.9 x 28.1 x 7.8 inches
MT550W7 MultiTaction Cell 55" Full HD LCD Embedded Windows 7
-
Allows multi-touch applications to be run without an external computer
-
55" display unit: physical dimensions 1242 x 713 x 199 mm / 48.9 x 28.1 x 7.8 inches
MT420S MultiTaction Cell 42" Full HD LCD Stackable
-
Modular, stackable to any size and shape
-
42" display unit: physical dimensions 965 x 557 x 200 mm / 38.0 x 21.9 x 7.9 inches
MT420W7 MultiTaction Cell 42" Full HD LCD Embedded Windows 7
-
Allows multi-touch applications to be run without an external computer
-
42" display unit: physical dimensions 965 x 557 x 200 mm / 38.0 x 21.9 x 7.9 inches
Key features of the MultiTaction technology platform:
- Computer Vision Through Screen (CVTS) recognizes unlimited number of fingertips, fingers,
hands and objects simultaneously.
- Extensible Hybrid Tracking System (EHTS) eliminates sensitivity to external lighting.
- Integrated Backlight Emitter Camera (IBEC) modules with embedded Matrix Tracking System
(MTS) provide the industry only touch system integrated into the LCD backlight plane.
- Works on Mac, Linux and Windows environments.
- MultiTaction Engine provides tracking output in all common formats and works with available
software development kit to utilize all advanced features
Download the Product Brochure for:
Download the Specification sheets for:
Learn more about MultiTaction Cell
The MultiTouch Cell Advanced is less than 30 cm deep. There are Standard and High Brightness models available:
MT467 MultiTouch Cell 46” Advanced Full HD LCD
- Tracks unlimited touch points, including hands, fingers, fingertips, 2D markers, real-life objects
- Modular, stackable to any size and shape
- Can be set up as a wall or as a table
- Frameless thin bezel design with smooth edge-to-edge front safety glass
- Frameless hardware design, easily integrates into custom furniture
- Screen brightness: 300 nits
MT469 MultiTouch Cell 46” Advanced High Brightness Full HD LCD
- Tracks unlimited touch points, including hands, fingers, fingertips, 2D markers, real-life objects
- Modular, stackable to any size and shape
- Can be set up as a wall or as a table
- Frameless thin bezel design with smooth edge-to-edge front safety glass
- Frameless hardware design, easily integrates into custom furniture
- Screen brightness: 500 nits
Download the Product Brochure for MultiTouch Cell Advanced (A4)
Download the Product Brochure for MultiTouch Cell Advanced (US Letter)
Learn more about MultiTouch Cell Advanced
Discontinued MultiTouch® Products
Note: Discontinued products are no longer available from MultiTouch.
Spare parts are still available and all discontinued products will still be maintained by MultiTouch for the length of their product guarantees.
MultiTouch Cell displays are 60 cm deep. It is easily stacked to form large multi-touch display areas. MultiTouch Cells can be piled on the top of each other just like building blocks to form vertical, multi-user and multi-touch installations.
MultiTouch Cell Advanced Displays are Available in Standard and High Brightness:
MT460 MultiTouch Cell 46” Full HD LCD
- Tracks unlimited touch points, including hands, fingers, fingertips, 2D markers, real-life objects
- Modular, stackable to any size and shape
- Can be set up as a wall or as a table
- Frameless thin bezel design with smooth edge-to-edge front safety glass
- Frameless hardware design, easily integrates into custom furniture
- Screen brightness: 300 nits
MT465 MultiTouch Cell 46” High Brightness Full HD LCD
-
- Tracks unlimited touch points, including hands, fingers, fingertips, 2D markers, real-life objects
- Modular, stackable to any size and shape
- Can be set up as a wall or as a table
- Frameless thin bezel design with smooth edge-to-edge front safety glass
- Frameless hardware design, easily integrates into custom furniture
- Screen brightness: 500 nits
Download the Product Brochure for MultiTouch Cell
Learn more about MultiTouch Cell
